WeatherKing® Versus™ Heat Pump, 208-230 V, 33 A, 284 W, 1/5 hp, 60 Hz, 1 ph, 850 rpm Rotational Speed, 60000 Btu/hr, 4396 cfm, 9 EER Rating, 14.3 SEER, 7.5 HSPF, Scroll Compressor, R-454B Refrigerant, 3/8 in Liquid Line, 7/8 in Suction Line, 50 A Fuse Rating, 2-Row, 22.7 sq-ft Inner, 23.4 sq-ft Outer, 20 FPI Coil, Tonnage: 5 ton, 74 dB Sound Level, 2 Stages, Steel, 39.17 in H x 35.543 in W x 35.543 in D
Note: TACL and EPA license required to buy refrigerant and refrigerant bearing equipment, RUUD® not available in Houston locations
| CFM Rating | 4396 cfm |
| Coil Rating | 2-Row, 22.7 sq-ft Inner, 23.4 sq-ft Outer, 20 FPI |
| Compressor Type | Scroll |
| Dimensions | 39.17 in H x 35.543 in W x 35.543 in D |
| EER Rating | 9 |
| Frequency Rating | 60 Hz |
| Fuse Rating | 50 A |
| HSPF Rating | 7.5 |
| Number of Stages | 2 |
| Power Rating | 284 W |
| Rotational Speed | 850 rpm |
| SEER Rating | 14.3 |
| Series | Select™ Series |
| Sound Level | 74 dB |
| Tonnage | 5 ton |
| Voltage Rating | 208-230 V |
| Amperage Rating | 33 A |
| BTU Rating | 60000 Btu/hr |
| HP Rating | 1/5 hp |
| Phase | 1 ph |
| Material | Steel |
| Refrigerant Type | R-454B |
- Fully Louvered Steel Cabinet: Features durable construction to add protection from yard hazards and weather corrosion
- Two-Stage Scroll Compressor1: Features two speeds (high and low) of cooling and heating, providing more precise temperature control, lower humidity and greater efficiency when compared to single stage compressors
- Inverted Reversing Valve: Allows for faster heat transfer with gravity assist shifting and reduced joint stress for increased reliability
- Expanded Valve Space: Provides a minimum working area of 27-square inches for easier access
- Designing for Sustainability with Low GWP: For 2025, the Environmental Protection Agency (EPA) has set a global warming potential (GWP) limit of 700 for refrigerant used in heating and cooling systems, This new requirement will result in a 78%2 lower GWP than previous-generation refrigerants - with only minimal changes to system installation, For us, this is another step toward our continued sustainability goal of reducing greenhouse gas emissions, while still delivering an exceptional level of energy efficient, dependable comfort
- PlusOne® Refrigerant Detection System™: An integrated one-box, patented design featuring the A2L sensor and mitigation board, offering easier commissioning with a single component and simplified wiring configuration, compatibility with any 24V thermostat application and system protection by automatically pausing outdoor unit operation - if excess refrigerant is detected
