ADP® premier evaporator coils match perfectly with your system, providing an upgrade over standard matched coils. ADP® coils are thoroughly tested to ensure optimal quality and deliver reliable ratings. They are uniquely designed to save customers time on installation, while ensuring a leak-free system. ADP® premier evaporator coils are the perfect solution for your application.
ADP® Housing Evaporator Coil, 48 MBtu/hr, 3 to 5 ton, R-410A, Uncased Coil, 19 in H (Note: TACL and EPA license required to buy equipment)
| Dimensions | 19 in H |
| Refrigerant Type | R-410A |
| Coil Type | Uncased |
| Tonnage | 3 to 5 ton |
| BTU Rating | 48 MBtu/hr |
- High-efficiency lanced fin design
- R-22, R-410A, AC and heat pump compatible
- All coils have durable packaging with bar-coded labels on the box
- Coils are air pressure tested at 500 lb/sq-in, leak tested with helium, sealed with rubber plugs and then charged with dry air
- Downflow drip shields are molded into drain pan
- Filter friendly top plate on most model (except 22 in and above)
- Down turned headers are sized out to easily receive lineset
- Factory software for TXV failure testing
- Dedicated upflow/downflow
- Copper refrigerant connections for easy brazing
- Rifled copper tubing
- Manufactured housing (uncased) coil
- Leak-free rubber plugs - suction and liquid lines do not require cutting for installation
- Pressure tested twice - ensuring superior performance at higher R410A operating pressures
- Includes die-cut foam sheet for sealing, drain ELL, drain hose and clamp
