RUUD® Endeavor™ Gas Furnace, Series: Classic Series, 75000 Btu/hr Input BTU Rating, 60000 Btu/hr Output BTU Rating, 115 V, 9 A, 1608 cfm Rating, 3/4 hp Rating, 0.8 % AFUE, 22 kW, 1 ph, 60 Hz, 1 Stage, Horizontal Upflow Configuration, NPT Connection Type, 1/2 in Connection, Electric, 11 in D x 7 in W Blower Size, 34 in H x 21 in W x 29.59 in D Cabinet Dimensions, Constant Torque Motor, Vent, Ducted or Ductless, 2 to 3 in Vent Size, 4 ton Tonnage, Direct Spark Ignition, 0.05 kPa, 25 to 55 deg F Rise
Note: TACL and EPA license required to buy refrigerant and refrigerant bearing equipment, RUUD® not available in Houston locations
| Series | R801T |
- PlusOne® Diagnostics - industry first, seven segment LED for quick and easy service
- PlusOne® ignition system Direct Spark Ignition (DSI) for reliability and longevity
- Low profile, 34 in cabinet makes our furnaces ideal for space constrained installations
- Hemmed cabinet and door edges and quarter turn door fasteners (up flow/horizontal only) - allows for safe, tool less access and serviceability
- Pre-marked hoses - offers easier identification and installation
- Blower shelf design ensures serviceability in all furnace orientations
- Replaceable collector box - enables replacement of only the collector box and doesn't require replacement of the heat exchanger
- Venting with 2 in or 3 in PVC - offers options that can be used on all furnace heating input sizes
- Self-priming condensate trap - allows for on-going water saturation within the trap to keep it primed and eliminates the need for seasonal service on the condensate trap
- Removable heat exchanger - built with a primary aluminized steel and secondary stainless steel construction, provides maximum corrosion-resistance, thermal fatigue reliability and improved serviceability
