Harris® Purging Regulator, Model: 601-800-580, CGA-580 x SAE Flared Connection, Argon Gas, Helium Gas, Nitrogen Gas Fuel, 3000 lbf/sq-in, Brass, 10.24 in H x 7.28 in W, Additional Information: Light to Medium Duty
| Connection Type | CGA-580 x 45 deg SAE Flared |
| Dimensions | 10.24 in H x 7.28 in W |
| Model | 601-800-580 |
| Fuel Type | Argon Gas, Helium Gas, Nitrogen Gas |
| Pressure Rating | 0 to 800 lbf/sq-in Delivery Range, 1450 lbf/sq-in Delivery Gauge, 4500 lbf/sq-in Supply Gauge, 3000 lbf/sq-in Maximum Inlet |
| Material | Brass |
- For applications where weight, cost and size are critical factors
- Ideal for HVAC purging, pressure testing and blanketing
- Higher end features at an economical price
- Brass body and bonnet for longer service life
- Ergonomic ABS plastic knob for easy grip and precise adjustments
- 50mm ABS plastic dual scale easy-to-read gauges
- One-piece encapsulated seat design with internal filter to protect the PTFE Teflon® seat from particulate contamination
- Neoprene diaphragm for improved pressure control
- Equipped with rubber gauge guards for added protection in abusive conditions
- Conveniently packaged in clamshell for point-of-purchase display
