We engineered our Next Gen R Series air cooled condensing units to provide a winning combination of high quality, increased flexibility and efficiency for lower long term operating costs. A key feature is the integral sub cooling circuit that allows saturated liquid to flow from the receiver to the condenser where refrigerant is subcooled by ambient air-providing an average of 3 to 5 deg F of sub cooling for higher efficiency and excellent operating stability.

Russell Flooded Extended Medium Temperature Scroll Air Cooled Condensing Unit, Series: Next-Gen MiniCon R, 208/230 V, 15 A, 4-1/2 hp, 3 ph, 60 Hz, R-404A Refrigerant, 5/8 in, 1-1/8 in Connection, 74 dBA Sound Level, Steel, Finish: Galvanized/Painted, 30 deg F, 90 deg F, 35 in H x 43-7/8 in W x 33 in D

• Low cost hermetic efficient compressor
• Extended range medium or low temperature Models with or without flooded head pressure control
• All weather galvanized steel painted housing
• Integral liquid sub cooling circuit provides subcooled liquid to the expansion device
• Generously sized high efficiency condenser, enhanced copper tubes/aluminum fins
• Quick access to shut off valves from exterior
• Liquid line kit with filter/drier and sight glass with moisture Indicator
• Suction line piping, Crankcase heater
• Larger electrical panel with hinged/removable door
• Color-coded point-to-point wiring
• Refrigerant receiver with isolation valve and pressure relief plug
• Encapsulated high pressure (auto reset) and low pressure (auto reset) controls (adjustable low pressure control is standard on low temperature models)
• Vintage units feature PSC motors

• Brochure https://assets.unilogcorp.com/297/ITEM/DOC/RU_RFH_0423A-2.pdf
• Catalog https://assets.unilogcorp.com/267/ITEM/DOC/Russell_RFO150E4S_DANT_Catalog.pdf
• Instruction/Installation Manual https://assets.unilogcorp.com/267/ITEM/DOC/Russell_RFO150E4S_DANT_Instruction_Installation_Manual.pdf
