The base HXX fan coil is an open blower-type (non-enclosed) fan coil. It is also available with either a field or factory installed enclosure, with both options of either a louvered or solid ceiling panel. For HXX fan coils factory installed within an enclosure, add -C after the kW in the Model number.
First Co.® Ceiling Fan Coil, Series: HXX Series, Model: R410 TXV, 240 V, 46 A, 10 kW, 1/2 hp HP Rating, 36000 Btu/hr, 1200 cfm CFM Rating, NPT, 60 A Fuse, 3 ton, Ceiling Mount, Aluminum, 58-3/4 in Overall Length, 23-7/8 in Overall Width, 11 in Overall Height, Additional Information: 10 in H x 56-1/4 in W x 21 in D Dimensions
| CFM Rating | 1200 cfm |
| Connection Type | NPT |
| Fuse Rating | 60 A |
| Model | R410 TXV |
| Overall Height | 11 in |
| Overall Length | 58-3/4 in |
| Overall Width | 23-7/8 in |
| Power Rating | 10 kW |
| Series | HXX Series |
| Tonnage | 3 ton |
| Voltage Rating | 240 V |
| Amperage Rating | 46 A |
| BTU Rating | 36000 Btu/hr |
| HP Rating | 1/2 hp |
| Material | Aluminum |
| Mounting Type | Ceiling |
- High efficiency ECM motor
- Drain pan has 3/4 in NPT primary and secondary (overflow) fittings
- Factory installed electric heat
- Highly efficient copper tube/aluminum fin cooling coil with factory installed R410A TXV
- Insulated and coated galvanized steel drain pan is sloped for proper drainage
- Effective January 2016, cabinet air leakage is no more than 2% when tested in accordance with ASHRAE 193
- Attractive off-white return air/access panel with captive screws, they can be used with either the non-enclosed HXX or the HXX with a field or factory installed enclosure
- Field installed enclosure, all enclosures are fully insulated and include cutouts for optional ducted return air, ducted return air option requires remote filter Grille
- Heat pump kit - required for all HXX Models having electric heat (#942-1)
- Condensate overflow switch (# SS3) (field installed)
- Enclosure cap kit - for ceiling installation
